10–33 kW Capacity
Model options of 10, 11, 14, 17, 20, 24, 28 and 33 kW suit a wide range of pool volumes.
Pool Heat Pump
Varm Silent Pool Series
Developed to maintain balanced water temperatures in villas, gardens and outdoor pool projects, the Varm Silent Pool Series combines R32 refrigerant, quiet operation and Wi-Fi-enabled control with energy-efficient pool comfort.
20–130 m³ Pool
COP 4,8 – 7,2
R32
Wi-Fi Control
Panasonic Compressor
Titanium Heat Exchanger
ABS Plastic Housing
Highlights
Quiet pool comfort with powerful and balanced performance.
The Varm Silent Pool Series delivers year-round pool comfort for villas and garden projects through quiet operation, balanced water temperature and a durable design.
Heating and Cooling
It heats pool water evenly and provides cooling support when needed for year-round comfort.
Smart Control
Wi-Fi-enabled controls simplify monitoring, management and everyday operation.
R32 Refrigerant
R32 refrigerant and an efficiency-focused system architecture support quiet pool projects.
The Varm Silent Pool Series adapts to poolside living spaces.
It supports heating and cooling comfort in villas, gardens and outdoor pool projects with quiet operation and balanced water temperature.
Technical Table
Varm Silent Pool Series technical specifications.
| Varmeks Model | VM-OP0102010 | VM-OP0102011 | VM-OP0102014 | VM-OP0102017 | VM-OP0102020 | VM-OP0102024 | VM-OP0102028 | VM-OP0102033 |
|---|---|---|---|---|---|---|---|---|
| Recommended Pool Volume (m³) | 20-40 | 25-50 | 30-60 | 40-75 | 55-100 | 70-130 | 60-120 | 70-130 |
| Operating Air Temperature (°C) | -7 ~ 43 °C | |||||||
| Heating Capacity (kW) – 27 °C | 9.50-21.00 | 11.00-25.00 | 14.00-31.50 | 17.00-37.50 | 20.00-40.00 | 24.00-48.00 | 28.00-56.00 | 32.50-65.00 |
| Heating Capacity (Btu) – 27 °C | 32300-71400 | 37400-85000 | 47600-107100 | 57800-130900 | 68000-136000 | 81600-163200 | 95500-191000 | 110900-221000 |
| Power Consumption (kW) – 27 °C | 1.46-4.14 | 1.83-5.17 | 2.15-6.21 | 2.62-7.25 | 3.33-10.27 | 4.00-10.32 | 4.75-10.37 | 5.42-10.43 |
| COP – 27 °C | 6.5-5.0 | 6.0-4.7 | 6.5-5.0 | 6.5-5.0 | 6.0-4.8 | 6.0-5.0 | 6.0-5.0 | 6.0-5.0 |
| COP at 50% Capacity – 27 °C | 11.00 | 11.00 | 10.50 | 11.00 | 11.00 | 11.00 | 11.00 | 11.00 |
| Heating Capacity (kW) – 15 °C | 7.2-15.0 | 8.5-16.5 | 10.7-24.0 | 13.0-26.5 | 15.6-28.5 | 18.7-34.2 | 21.8-43.6 | 25.4-50.7 |
| Heating Capacity (Btu) – 15 °C | 24480-51000 | 28900-56100 | 36380-81600 | 44200-90100 | 53040-96900 | 63580-116300 | 74380-148800 | 86665-173000 |
| Power Consumption (kW) – 15 °C | 1.43-3.21 | 1.77-3.23 | 2.12-3.44 | 2.58-3.36 | 3.25-4.40 | 3.89-4.49 | 4.54-4.62 | 5.29-7.02 |
| COP – 15 °C | 5.0-7.2 | 4.8-7.2 | 5.0-7.1 | 5.0-7.4 | 4.8-7.0 | 4.8-7.0 | 4.8-7.0 | 4.8-7.0 |
| COP at 50% Capacity – 15 °C | 6.50 | |||||||
| Cooling Capacity (kW) | 5,2 | 6,0 | 7,2 | 8,6 | 10,1 | 11,8 | 13,8 | 15,6 |
| Sound Pressure at 1 m (dB(A)) | 38-48 | 40-50 | 42-51 | 43-52 | 43-53 | 44-54 | 45-56 | 45-57 |
| Sound Pressure at 50% Capacity at 1 m (dB(A)) | 40 | 41 | 43 | 44 | 44 | 45 | 48 | 49 |
| Sound Pressure at 10 m (dB(A)) | 18-25 | 19-26 | 22-27 | 23-30 | 24-31 | 25-32 | 26-34 | 26-35 |
| Heat Exchanger | Spiral Titanium Tube in PVC | |||||||
| Enclosure | ABS Plastic Housing | |||||||
| Refrigerant | R32 | |||||||
| Power Supply | 230V/1Ph/50Hz | |||||||
| Compressor | Panasonic | |||||||
| Four-Way Valve | Sanhua | |||||||
| Expansion Valve | Sanhua | |||||||
| Heating Water Operating Temperature (°C) | 9-40 | |||||||
| Cooling Water Operating Temperature (°C) | 9-35 | |||||||
| Water Connection (mm) | Φ50 | |||||||
| Nominal Input Current at 15 °C Air (A) | 6.3-9.0 | 7.8-10.0 | 9.3-15.0 | 11.3-16.0 | 14.3-18.0 | 17.8-23.0 | 20.8-28.0 | 24.2-33.0 |
| Recommended Water Flow (m³/h) | 2-4 | 3-5 | 4-6 | 6-9 | 8-10 | 9-12 | 10-14 | 12-16 |
| Maximum Water Pressure Drop (kPa) | 3 | 4 | 5 | 5 | 6 | 8 | 20 | 25 |
| Net / Gross Weight (kg) | 62/70 | 64/72 | 77/87 | 81/91 | 81/91 | 95/105 | 110/122 | 115/127 |
| Product Dimensions (mm) | 1000×396×640 | 1000×396×640 | 1000×396×640 | 1000×396×640 | 1125×416×765 | 1125×416×765 | 1156×430×905 | 1156×430×905 |
| Package Dimensions (mm) (Carton) | 1040×410×780 | 1040×410×780 | 1040×410×780 | 1040×410×780 | 1165×430×905 | 1165×430×905 | 1230×440×1030 | 1230×440×1030 |
Test Conditions
Heating performance data is based on Air 27 °C / Water 26 °C / Humidity 80% and Air 15 °C / Water 26 °C / Humidity 70% conditions.
Cooling and sound data is evaluated at Air 15 °C / Water 26 °C / Humidity 70%.
* Installation must use PVC piping.
Heating performance data is based on Air 27 °C / Water 26 °C / Humidity 80% and Air 15 °C / Water 26 °C / Humidity 70% conditions.
Cooling and sound data is evaluated at Air 15 °C / Water 26 °C / Humidity 70%.
* Installation must use PVC piping.
Application
Where can Varm Silent Pool be used?
Ideal for villas and garden pool projects.
Application
Where can Varm Silent Pool be used?
It heats and cools pool water evenly in villas, gardens and outdoor living spaces. Its quiet operation suits comfort-focused projects.
Capacity
How is the right capacity selected?
Pool volume and climate conditions are evaluated together.
Capacity
How is the right capacity selected?
Capacity should be selected according to pool volume, usage pattern and local climate. The right model directly affects efficiency and heating time.
Project
What information is needed for a quote?
Pool dimensions and the usage scenario are sufficient.
Project
What information is needed for a quote?
Sharing the pool dimensions, approximate water volume, usage period and existing system details helps our team recommend the right Silent Pool model.
Let us determine the right capacity for your Varm Silent Pool Series project.
Contact our sales and engineering team to select the right model, capacity and system configuration for your project.
Your request will be reviewed promptly by our engineering team.
